Safety Switch
Materials
| Hardware | Qty |
|---|---|
| D2HW-C202MR Switch | 1 |
| M3x10 SHCS | 1 |
| M3x8 SHCS | 1 |
| M3 Roll-In Nut | 1 |
| Cables |
|---|
| Z-114 |
| Z-115 |
| Printed Parts | Qty |
|---|---|
| Safety Switch Bracket | 1 |
| Cable Cover 55mm | 1 |
Animated Assembly
Assembly Notes
- 7:22 This is preliminary. The exact height of the safety switch adjustment screw will be set in the Checks and Calibration section.
- 7:42 Cables and Hardware are listed in Force Sensors.
- 8:08 Continue to Routing Pod
